6V6

Tetrode · IHT · Octal · 1937

Small-amp magic.

Beam power tetrode rated at 12W for high-power output stages

Datasheet ↗SPICE
TRANSCONDUCTANCE0mA/V
GAIN0%
POWER30%
DRIVE50%
LINEARITY75%
HEATER6.3V / 0.45A
MAX PLATE350V / 12W
BASEoctal
EXECUTIVE SUMMARY

The 6V6 is a compact beam power tetrode delivering about 4.5W in single-ended or 14W per pair in push-pull, and is the quintessential small American amplifier tube. It is the output tube of the Fender Champ, Deluxe, and countless other small combo amplifiers prized for their warm, compressed, touch-responsive overdrive character. The 6V6 breaks up earlier and more gracefully than the 6L6, with a sweeter, more vocal distortion character that has made it a favorite for blues and roots guitar players. Matching can be critical as the tube operates near its limits in many designs; RCA and Sylvania NOS remain the gold standard.

HISTORY
Introduced1937ManufacturerRCA·SylvaniaEquivalentsCV511
Pre-War
SPECIFICATIONS
Heater Voltage6.3V
Heater Current0.45A
Max Plate Voltage350V
Max Power12W
Sensitivity4.1 mA/V
Gain Factor
Internal Impedance
PinoutOctal
Era1937
RarityCommon
PDF

6V6 Datasheet

Frank's Electron Tube Pages · PDF

CLASSIC CIRCUITS
Fender Tweed Deluxe360V · PP
